3. By leaving the knob in the central position, the airflow is equally distri-
buted inside the passenger compartment
Adjusting the air vents:
In addition to controlling the airflow using the knob, it is possible to mecha-
nically adjust the flaps placed on the sides of the unit to manage the airflow.
The flaps can be positioned as follows:
1. Closed position. The flaps are left closed; the air is distributed vertically,
obtaining a breeze effect that generates a delicate and comfortable air-
shower effect in a limited area around the air conditioner.
2. By opening the flaps in the 3 positions using the relevant intakes, diffe-
rent directions and intensities of air flow will be obtained as indicated in the
drawin
Side view with
closed flaps
Flaps open 1
Flaps open 3
Flaps open 2
Equally-distributed flow
Frontal flow
Rear flow
