mecalac 14 MBX - 9.4 Turntable Supply and Return Circuit

14MBX 30750
28 M1
9.4 Turntable supply and return circuit
P
LS
T
M
T
P
T
P
4
5
2
3
1
7
6
8
T
1
P
A
P
T
1
T
P
3A
1
8
2
PS
A2
P
LS
A
M1
M2
D1
C9
D7
D6
D6
D5
D5
B6
C1
C2
C10
D2
B3B2
B1
D4 D4D3
B1 - Parking brake control
B2 - Brake foot control
B3 - Accelerator foot control
B6 - Rotary coupling
C1 - SX18 valve block
C2 - Left manipulator
C9 - Drain block
C10 - Functions block
D1 - Right manipulator
D2 - Valve
D3 - Accumulator 0.35 l 1.5 bar
D4 - Accumulators 0.7 l 18 bars
D5 - Non-return valves
D6 - Nozzle / non-return valve
D7 - Non-return valve
