30750 14MBX
M1 73
15. Control Sheet
Machine no.:
Engine no.:
Equipment pump no.:
Transfer movement pump no.:
Transfer movement engine no.:
Note: In order to obtain the best from our after-sales service, you should fill out this control
sheet correctly before sending it.
In order for the breakdown to be diagnosed properly, describe it on the back of this
page.
Stated
or
regulated values
14 MBX Description
adjustment values Speed Pressure
Rpm bars
Engine
Max. engine speed 2,300 (+20 -20)
Min. engine speed 950 (+50 -0)
Direction
Primary controller 250 (+5 -0)
∆ P, right 225 (+5 -5)
∆ P, left 225 (+5 -5)
Equipment
Assistance pressure 36 (+3 -0)
Equipment
∆ P 15 (+1 -1)
Max. pump pressure (D.R.) 340 (+10 -0)
Max. equipment pressure 310 (+5 -5)
Power regulation (140 l) 245 (+10 -10)
Transfer movement
Maximum power-feed regime. 28 (+2 -1)
Starting 1,100 (+50 -30)
H.P. transfer movement (D.R.) 440 (+10 -10)
Heat grind 1,700 (+50 -50)
Adjustment of transfert 250 (+10 -10)
movement engine
Minimum capacity FRANCE 2,450 (+25 -25)
Minimum capacity GERMANY 1,700 (+25 -25)
