mecalac 14 MBX - 9.14 Fitting of 4 Safety Valves on the Equipment (Option)

14MBX 30750
38 M1
9.14 Fitting of 4 safety valves on the equipment (option)
D
T
M
C
T
P
M
V2
V2
A
T
P
M
V2
T
P
B
T
P
M
V2
b b
b
a
A
3C
T
F4
N1
C1
C6
B6
F5
M4
F3
G1
M3
M2
M1
B6 - Rotary coupling
C1 - SX18 valve block
C6 - Turntable rotation, brake release block
F3 - Dipper ram
F4 - Intermediate boom ram
F5 - Boom ram
G1 - Bucket ram
M1 - Boom ram valve
M2 - Load detector
M3 - Intermediate boom ram valve
M4 - Dipper ram valve
N1 - Bucket ram valve
