30750 14MBX
M1 45
12. Location of the electric components
12.1 Solenoid-operated valves
Designation
Y1 Hydraulic lock solenoid-operated valve (power-assistance pressure block)
Y2 Inversion of direction of bucket solenoid - operated valve
Y3 Coupling of rams solenoid-operated valve
Y4 “MECALAC 2” option solenoid-operated valve (control unit)
Y5 Boom / inter. boom solenoid-operated valve (control unit)
Y6 Boom / inter. boom solenoid-operated valve (control unit)
Y7 Tool unlocking solenoid-operated valve
Y8 Left offset solenoid - operated valve (hydraulic functions block)
Y9 Load sensing solenoid - operated valve (hydraulic functions block)
Y10 Right offset solenoid - operated valve (hydraulic functions block)
