14MBX 30750
54 M1
14.1.2 Adjustment during minimum regime
(slowed down)
1- Loosen the lock nut and turn the stop screw
(1 fig. 1).
Note: Number of teeth on engine wheel: 159.
Note:
For the air-conditioning version of the
machines,
minimum regime = 1,050 (+ 50 - 0)
1
13 flat spanner
Flat screwdriver
Inductive sensor
Operation
Speed
(rpm)
Adjustment
(ref. no.)
Minimum regime 950 (+ 50 - 0) 1 fig. 1
Fig. 1 Injection pump
Fig. 2 Heat engine
1
