Medeli DD508DX User Manual

Selecting a Drum Kit
The digital drum has 10 Pad triggers and 1 pedal
controller see Table Trigger MIDI Note below:
Note:
1. You can select Close Hi-Hat (Close Hi-Hat Rim) by
press Pad Select button [HI-HAT CONTROL] and
[HI-HAT] simultaneously.
2. When using Pad Select button, some of the pad
trigger can't be selected, for example: RIDE BELL,
Half Open Hi-Hat, Half Open Hi-Hat Rim, Splash.
And thus, you should strike a pad to select the
above triggers.
Selecting Pad
The current pad to be edited can be selected either by pressing
its Pad Select button or by striking the pad itself.
Pad Selected
Ride Bell
Half Open Hi-Hat
Half Open Hi-Hat Rim
Close Hi-Hat
Close Hi-Hat Rim
Splash
Pad Select indicator
[RIDE] sparkling
[HI-HAT] lighten, [HI-HAT CONTROL]
sparkling
[HI-HAT] lighten, [HI-HAT CONTROL]
sparkling, [RIM] lighten
[HI-HAT] lighten, [HI-HAT CONTROL]
lighten
[HI-HAT] lighten, [HI-HAT CONTROL]
lighten, [RIM] lighten
[HI-HAT CONTROL] lighten, [RIM]
sparkling
Meaning for Pad Select button LED
11
PAD
1
2
3
4
5
6
7
8
9
10
Pedal
TRIG NUM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
NAME
KICK
SNARE
SNARE RIM
TOM1
TOM1 RIM
TOM2
TOM2 RIM
TOM3
TOM3 RIM
TOM4
TOM4 RIM
RIDE
RIDE RIM
RIDE Bell
CRASH1
CRASH1 RIM
CRASH2
CRASH2 RIM
Open HIHAT
Open HIHAT RIM
Half Open HIHAT
Half Open HIHAT RIM
Close HIHAT
Close HIHAT RIM
Pedal HIHAT
Splash
MIDI Note
36
38
40
48
50
45
47
43
58
41
39
51
59
53
49
55
57
52
46
26
23
24
42
22
44
21
0
5
25
75
95
100
