Medeli DP250 User Manual

Setup
7
B. Put the piano cabinet [1] on the stand, fix it with Screw BM 6*24mm [6].
C. Insert the pedal cable [9] into the proper socket of the cabinet [1].
Setup Guide
A. Fix and well tighten the left and side boards [4] & [5] to the
Support Plate[2] with Screw CM6*50mm(4pcs) [7] and nut M6
[10] . The screw Cover(4pcs) [8] above Screw CM6*50mm
(4pcs) [7].
right
Screw CM6*50mm [7]
Screw Cover [8]
Screw BM6*24mm [6]
Nut M6(4)
