Medeli DP740K - Setup; Component Guide; Setup Guide

Setup
04
1
2
5
6
6
8
8
9
9
4
3
This section contains information about setting up your instrument and preparing to play. Please read through this section
carefully before turning the power on.
Component Guide
Check that all the parts listed below are included before proceeding to the Setup Guide.
Setup Guide
To assemble the stand, you will need a Phillip's screwdriver (not supplied).
11
11
12
13
7
7
10
10
Piano body
Left stand component
Right stand component
Pedal assembly
Back board
Screws 6x12 BM (2PCS)
Screws 4x15 PA (4PCS)
Screws 6x18 BM (4PCS)
Hand screws (2PCS)
Screws 6x50 PA (4PCS)
Screw caps (6PCS)
Pedal cable
AC power adaptor
1
2
3
4
5
6
7
8
9
10
11
12
13
