3 Interface and Connectors
3.1 Genio 350-EVK I/O Connectors
DC Jack CN1403 12V DC Input
System Power Indicator D1206 Green
Reset Indicator D1207 Green
System Power Indicator D1001 Green
Charging Status Indicator D1 Red
Power On Button CON001
Volume-Up Button CON002
Volume-Down Button CON003
Reset Button CON004
USB Device CON1 ADB Debug Port
USB Host CN1701
UART0 CON461 CPU Log
UART1 CON462 DSP Log
Micro SD Card Slot CN460
DSI J2321 LCM
I2C1 CN1709 Touch Pad
CSI0 CN301 Camera 0 Sub-Board
CSI1 CN170 Camera 1 Sub-Board
HDMI CON3000
HDMI Type-A
Connector
Ethernet CN1502 10/100Base-T
M.2 Slot J600 WiFi Module
IrDA Receiver J1303
Raspberry Pi like I/O J2303
JTAG J2305
Earphone Jack J700
Line Out J2304
Battery Connector CON200
Analog Microphone U700
Digital Microphone 0 U701
Digital Microphone 1 U702
Table 3-1 Main Board Connectors
