MEDIATEK Genio 350 - I2 C; SPI; PWM; Raspberry Pi like I;O Interface

Genio 350 EVK
Genio 350 Evaluation Kit Hardware User Guide
Unclassified
MediaTek Proprietary and
Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document, in whole or in
part, is strictly prohibited.
Page 13 of
24
I2C Bus Purpose Note I2C Bus
I2C0
Battery Charger
Raspberry Pi I/O
RichTek RT9466GQW
I2C0
I2C1
Capacitive Touch Controller
HDMI Bridge IC
Goodix GS9271
ITE IT66121FN
I2C1
I2C2
Camera Sub-Board (MIPI CSI0)
Raspberry Pi I/O
I2C2
I2C3
Camera Sub-Board (MIPI CSI1)
I2C3
Table 3-5 I2C Bus
SPI
• Support Master/Slave mode
• One chip select output.
PWM
• PWM supports Old mode and FIFO mode
• The frequency can be set from 0Hz to 39MHz
Raspberry Pi like I/O Interface
The pin definitions are as followings:
Pin # Description Note Pin # Description Note
1 3.3V 2 5V
3 SDA2 Camera 0 I2C 4 5V
5 SCL2 Camera 0 I2C 6 GND
7 IO124 8 TXD2 GPIO40
9 GND 10 RXD2 GPIO39
11 IO127 12 IO22
13 IO33 14 GND
15 IO109 16 IO136
17 3V3 18 IO137
19 SPI_MO GPIO29 20 GND
21 SPI_MI GPIO28 22 IO140
23 SPI_CLK GPIO27 24 SPI_CS GPIO26
25 GND 26 IO141
27 SDA0 GPIO57 28 SCL0 GPIO58
29 IO25 30 GND
31 IO142 32 PWM_A GPIO19
33 PWM_C IRRX 34 GND
35 IO144 36 IO139
37 IO138 38 IO34
39 GND 40 IO32
Table 3-6 Pin Assignments of the Raspberry Pi like I/O Connector
