Medline Alterra MAXX User Manual

4 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
SUMMARy OF FDA’S DIMENSIONAL
RECOMMENDATIONS
Key zones of the bed Dimensions
Gaps within the rail (Zone 1) <120 mm (< 4 3/4 “)
Under the rail, between rail
supports or next to a single rail
support (Zone 2)
< 120 mm (< 4 3/4 “)
Between rail and mattress
(Zone 3)
<120 mm (< 4 3/4 “)
Under the rail, at the ends of
the rail (Zone 4)
<60 mm (< 2 3/8 “) AND >60° angle
