$ <;<0:;
$,. 0:;
1. Paper insert
2. Paper End sensor
3. Printhead
4. Printer
5. Presenter sensor
6. Paper Exit sensor
7. Paper exit
8. Presenter motor
9. Cutter
07$
The GPT-4672-P / GPT-4673-P is a printer with loop presenter. The printout is saved in a loop during printing and is only
output as soon as the printing process has ended. By decoupling the output from the printing process, it can no longer be
disturbed by external manipulations. The output security is thereby signicantly increased.
The output speed can also be increased up to 500 mm/s.
It is selectable how far the printout leaves the presenter for removal. If the operator is pulling on the paper when removing
the printout, the presenter motor notices this and feeds the ticket towards the paper output.
If the ticket is not withdrawn after an adjustable period of time, it can either be fed out (eject) or withdrawn (retract).
A dispenser operation can also be set for thicker papers, which issues the ticket without forming a loop.
("(" ) " *+,-+,-+..% !"",'$/.,%.%%.
0"(! "(12 3 *+,-+,-+..'' .+4$%$.
5".6 )7 .%8..$
-$..%"7 "3971," 7"31"1)),
" ,71," "! "75,
9
4
8
5
3
6
7
1
2
5
