J2: Power supply
" 0"!" =
1 GND -
2 24 VDC -
3 Wakeup I
Socket: Phoenix MCV1,5/3-G-3,81
Mating connector: Phoenix MC1,5/3-ST-3,81 1 mm²
J6: USB interface plug
" 0"!" =
1 USB Power -
2 GND -
3 D- I/O
4 D+ I/O
5 Frame -
Socket: Molex 53398-0571
Mating connector: Molex 51021-0500
Crimp contacts: Molex 50079-800 AWG 28 - 26
J5: RS232 interface plug
" 0"!" =
1 GND -
2 V24 TXD I
3 V24 RXD O
4 V24 RTS I
5 V24 CTS O
Socket: JST SM05B-SRSS-TB
Mating connector: JST SHR-05V-S.B
Crimp contacts: JST SSH-003T-P0.2-H AWG 32 - 28
("(" ) " *+,-+,-+..% !"",'$/.,%.%%.
