Parts list / spare parts:
2“ printer module with presenter GPT-4672-PM
K..-6 $'$$%;&/,$
1 13911 GPD-HSP2208-KSR-GB
2 XG5033 XGCT-46620-1v4b-Var01-V.24_USB-F24 Pow_off-CUT_PRE-HSP2xxx
3 FN1136 plug 3 pin Phönix FN59-990231-B
4 FN1187 insertion bridge 1x2p
5 13706 cable PCB – presenter GKA-593-2-70-20p
6 13705 cable PCB – printer GKA-594-2-60-28p
7 HN0186 HN14-5755-B-EJOT-PT-screw KA30x8 (for controller 3x)
8 HM3017 HM-4672-0101-04-SG chassis
9 HM3018 HM-4672-0111-01-width adjuster 2Zoll
10 HN2846 EJOT-DELTA PT 25x6 W5451 pan head screw with washer / Torx
11 HM2915 HM-6773-0501-01-a-keycap-V0
HM3166 HM-6773-0501-01-a-keycap-signal green-V0
12 GN1182 lightpipe-GMT-4379-200-00
HN0186 HN14-5755-B-EJOT-PT-screw KA30x8 (for DW 2x)
LN1422 LN13-1302-B-thermal foil
Presenter:
13 13704 GMT-4672-P Paper Loop Presenter Unit -GB 2“
14 HN1422 EJOT-PT-30x6-TORX-screw /A2K3,6 (for presenter 2x)
16 HN2777 EJOT-PT-screw 18x5,0 WN1452 (for locking plate 2x)
17 HM3120 HM-4672-1501-01-presenter locking plate
