Parts list / spare parts:
Mounting bracket and bezel for GPT-4673-PM
07-6
K.$%6'""71!(
1. HM3149 HM-4673HM-4673-0311-01-e-mounting bracket for loop presenter
2. HN2683 screw M3x15 DIN7985-DIN EN 7045
K..'1N
1. HM3090 HM-4673-0701-01 SG output bezel 3“
2. HN1148 knurrled nut M3x8 DIN464
3. HN0600 hex nut M3 DIN985 ISO7043
Optional accessory:
1. 14216 GMT-467x-Bezel locking set
2. 14223 GMT-467x-Bezel screw fastening
3. 14218 GMT-4673-sealing ring
4. 14221 GMT-4673-Bezel adhesive tape upper position
5. 14222 GMT-4673-Bezel adhesive tape lower position
("(" ) " *+,-+,-+..% !"",'$/.,%.%%.
