25
T
est Lead selection
Split conductor Fused test lead set (1 pair)
Megger Part Number 1002-015
Retractable sheath fused test lead (1 pair)
Megger Part Number 1006-511
must
be used on power systems
Other test leads and the BNC adapter
must
only be used on low voltage systems
24
26
