32
Note: When the battery is charging, fast transients can cause the display to go blank. This will not normally affect
the charging operation.
(ii) External 12 V d.c. source
Fuses (Non replaceable):
Mains supply protection: 200 mA (T) ceramic HBC 20 mm x 5 mm to IEC 127/3
Battery protection: 2 A (T) ceramic HBC 20 mm x 5 mm to IEC 127/3
Battery in-line protection: 3,15 A (T) ceramic HBC 20 mm x 5 mm IEC 127/3
External 12 V supply protection: 2 A (T) ceramic HBC 20 mm x 5 mm IEC 127/3
Output current protection: 80 mA (F) glass 20 mm x 5 mm
Fuse (Replaceable):
Mains power cord fused plug: 3 Amp fuse to BS 1362
Safety: Meets the requirements for safety to IEC 1010-1 1995) EN61010-1
(1995).
E.M.C: In accordance with IEC61326 including amendment No.1
Dimensions: 344 mm x 245 mm x 158 mm
Weight: 5 kg
Cleaning: Wipe the disconnected instrument with a clean cloth dampened with
soapy water or Isopropyl Alcohol (IPA).
Specification
