Megger DLRO - Safety

Specifications
AVTM24-1J REV A April 2006
11
Safety: Meets all applicable requirements
of ANSI/ISA S82.01-1994.
Highest voltage existing (except in
charger primary and line supply
primary) is 6 volts.
Case: The measuring unit and charger
have rugged molded case with
handles and removable hinged
lids. The measuring unit lid can be
used as a sun shield. The charger
case has similar construction with
additional space for storing test
leads.
Test Lead
Terminals:
5/16” diameter studs with wing
nuts for spade or ring lugs.
Dimensions and Weights:
Cat. No. Weight Dimensions
lbs kg inches
cm
247000 11 5.01 8-7/8W x 8-1/8D x 8-1/8H
22.4 x 20.6 x 20.6(Instrument)
247000-47 - - 8-1/8W x 8-1/8D x 7-3/8H
22.4 x 20.6 x 18.8 (Charger)
247001 12.1 5.5 12W x 9 5/8D x 6 3/8H
30 x 24.5 x 16.2
247002 12.2 5.5 12W x 9 5/8D x 6 3/8H
30 x 24.5 x 16.2
