AVTMMTO210 Rev 7 Sept 2013
60
CODE Error Description Possible Cause
314 ADC channel 4 failed
4.0
HARDWARE_ERROR
401 Discharge takes too much time
402 VICOR protection failed, OVER is too long
or too short to reset
403 VICOR protection failed, OVER is too long
or too short to set
404 VICOR fast protection failed, OVER is too
long or too short to reset
405 VICOR fast protection failed, OVER is too
long or too short to set
406 Current Regulation failed at DAC=0
407 Current Regulation failed at 10mA range
408 Current Regulation failed at 100mA range
409 Current Regulation failed at 1A range
410 Current Regulation failed at 10A range
411 Current output not high enough
412 Too much ripple for Lamp On
413 Too much ripple for Lamp Off
414 Test Lamp voltage is too low
415 Test Lamp voltage is too high
416 Warning Lamp test failed
417 Remote lamp test failed
418 Relay test K1 on and K2 on failed
419 Relay test K1 off test failed
