Megger VLF SIN-45 User Manual

Technical Description
12
The optional VLF CR Test Boost (VLF CR-40-TB) is defined by the following technical
parameters:
Parameter Value
Output voltage,
cosine rectangular wave
3 … 40 kV
Output current
12 mA
RMS
Frequency
0.1 Hz
Testable load capacitance
4545455 μF at 40 kV
Weight
42 kg
Dimensions (W x D x H)
544 x 416 x 400 mm
Operating temperature
-20 °C to 55 °C
Storage temperature
-40 °C to 70 °C
Relative humidity
93% at 30 °C (non-condensing)
Protection class (in accordance with
IEC 61140 (DIN VDE 0140-1))
I
Ingress protection rating (in accordance
with IEC 60529 (DIN VDE 0470-1))
IP21
