Operating Modes
43
5.3.3 Evaluation of the Test Results
5.3.3.1 Automatic Evaluation
An automatic evaluation of the test results is only carried out if the following
requirements have been fulfilled:
• A standard for the evaluation of the test results has been selected.
• The selected standard contains criteria for the evaluation of the insulation type
of the connected cable.
• The test was conducted in respect of at least 3 voltage levels.
• The test was carried out on a test voltage with a frequency of 0.1 Hz.
The standard as well as the insulation type can be adjusted (see page 40) even
after completion of the test.
If an automatic evaluation can be performed, the results are shown in the centre of the
display:
