Completing the Work
47
6 Completing the Work
If there is a USB flash drive plugged in the USB port on completion of the
measurement / test, a log file (.csv) as well as a print-ready report (.pdf) are
automatically exported into the vlf45/measurements/ directory. If this was not the case,
the data records can also be exported from the history database (see page 29) at a later
stage.
The free EasyProt software is excellent for evaluating, printing and archiving the data
logs on a workstation PC and can be downloaded from the user area of
www.sebakmt.com.
After the measurements on a cable have been completed, the VLF SIN-45 test system
can be switched off by pressing the ON/OFF button
.
When disconnecting the test system, proceed in reverse sequence to the manner in
which the connection (see page 19) was made. The following safety instructions must
be strictly adhered to.
WARNING
• Follow the five safety rules (see page 8)
• Even if switched off properly and discharged using the discharge
device, the system components that were under voltage should only
be touched once they have been discharged using a suitable
discharge rod as well as having been earthed and shorted.
• Only undo the earthing and short circuiting measures when the test
object is to be operated again.
Exporting the
measured data
Shutting down the test
system
