Megger VLF SIN-45 - Normal Connection

Commissioning
19
3.1.1 Normal Connection
The following figure shows a simplified connection diagram of the VLF SIN-45 test
system:
Connection diagram
Station earth or other suitable
foundation earth electrode
110 V to 230 V,
50/60 Hz
Connection method for cable testing and loss
factor measurement
Connection method for sheath testing and
sheath fault pinpointing
