7 Combination with other test systems
The test system can be used together with the external Tan Delta test attachment for a
high-precision loss factor measurement. The test system and the data exchange with
the test attachment are controlled using a notebook on which the required software has
been installed. Because this software also allows the native operating modes to be run,
a notebook like this is also suitable for complete remote control of the test system.
Detailed information on the electrical connection of the Tan Delta test
attachment can be found in the corresponding operating instructions.
Operation of the software is described in the “Software for Remote Control of
a VLF Sine Wave Test System” manual.
If you require more exact information about the characteristics and prices of the Tan
Delta test attachment or the notebook required, please do not hesitate to approach your
Megger sales partner.
A test system equipped with the VLF CR Test Boost can be used as test voltage source
for the PDS 60 partial discharge measurement system. The notebook included in the
PDS 60 delivery scope is used to control the system and evaluate the test results.
Detailed information about the electrical connection, and about carrying out
the partial discharge diagnosis, can be found in the operating manual for the
PDS 60 PD measurement system.
If you require more exact information about the characteristics and prices of the PDS 60
partial discharge test system, please do not hesitate to approach your Megger sales
partner.
Loss factor
measurement using an
external test
attachment
Partial discharge
diagnosis using the PD
test system
