Chapter 1 – Device description
6
Views of the devices
Log printer
Fig. 1: Paper tray closed
(1) Cover
(2) SEL key
(3) LF key
Fig. 2: Paper tray open
(4) Paper tray
(5) Roll dispenser
(6) Transport key
(7) Ink ribbon
(8) Paper slot
(9) RS232 connection
(10) DC connection for power
supply
Fig. 3: Paper tray open
1
3
5
4
6
7
9
10
2
8
