Construction and description
2. Construction and description
2.1 Construction
1
2
3
4 5 6
1
7
8
°C22.4
TEMP
°CSet 37.0
TIMER
30m04h
Ende
23.Nov 13:30
LICHT
%
100
Fig. 2 Construction
1 ControlCOCKPIT with capacitive function
keys and LCD displays (see page 20)
2 On/Off switch (see page 18)
3 Chamber fan
4 Steel grid
5 Interior
6 Nameplate (see page 12)
7 Door handle (see page 19)
8 Turn control with confirmation key
