12 03/2021
Construction and description
2.7 Technical data
Model sizes 6 11 15 24 35 50
Stainless steel
interior Volume
ap-
prox.
l
7.5 10 17.1 23.1 37.5 51
Length A mm 277 267 482 472 602 592
Width B mm 217 207 277 267 482 472
Height C mm 150 200 150 200 150 200
Structured
stainless steel
housing
Width D mm 349 554 674
Height E1 mm 245 295 245 295 245 295
Height E2 mm 348 398 348 398 348 398
Depth F mm 289 349 554
Temperature Adjustment precision °C 0.1
Operating temperature range °C minimum 5 above ambient temperature to +100
Setting temperature range °C +10 to +100
electrical data Power 230 V; 50/60 Hz
W 1000 1420
2800
115 V; 50/60 Hz 2000
Current
consump-
tion
230 V; 50/60 Hz A 4.4 6.2 12.2
115 V; 50/60 Hz A 8.7 12.4 17.4
Packaging
data Net weight
ap-
prox.
kg
6 7 9 10 14 16
Gross weight (in cardboard box)
ap-
prox.
kg
10 12 14 16 20 23
Length mm 570 670 910
Width mm 450 530 610
Height mm 420 380 400 460 400 460
