Getting Started with MyChron 3
Aim has developed and tested your MyChron 3 to provide precise and
accurate results.
Here are the parts of your system:
• MyChron 3 Display Unit ( 1 ).
• RPM sensor ( 2 ).
• Thermocouple – In alternative you may choose Water Sensor ( 5 ), Exhaust
Gas Sensor ( 9 ) or Underspark Temperature Sensor ( 10 ). The Water
Temperature Sensor may be provided with an M5 connection or a 1/8
connection.
• Optional water thermocouple M5 fitting ( 11 ).
• Thermocouple extension cable ( not shown ).
• Lap Timer . May be optical ( 3 ) or magnetic ( 8 ). The optical one is provided
with the optical transmitter ( 4 ), while the second one may work only in the
kart tracks provided with a magnetic strip.
• External power wire for Infrared transmitter ( 6 ) for IR version.
• Optional USB data download cable ( 7 )
See also Fig. 1.1 on page 5.
