Memphis Pro - ITC Circuit Board Fuse Replacement

Memphis Grill Manual Rev. B 19
Troubleshooting:ITCCircuitBoardFuseReplacement
Troubleshooting:ITCCircuitBoardFuseReplacement


TheITC,orIntelligentTemperatureControlsystemonyourGrillisanintricate andvaluablepieceof
technology.Intheinterestofprotectionfrompowersurgesandelectricalshorts,theITCutilizesa5
Amp,120VoltFast‐Blowfuse.Thissimpleandinexpensivepartcanbeeasilyreplacedwiththe

followinginstructions.
1. Ensurethatthegrilliscool,powered‐down,andunplugged.
2. Supportingtheelectricalboxwithonehand,removethetwoPhillips‐headscrews
securingtheITCtothefrontofthegrill.
3. Ifpossible,leavealloftheconnectionsonthecircuitboardintact.Ifitisnecessary
to
removethemtoinspectthefuse,takenoteoftheirspecificlocation.Marking
connectionswithtapeisaconvenientwaytodothis.
4. InspectthebackoftheITC,takingnoteoftheconditionofthefusecurrentlyinplace.
Carefullyyetfirmlyremovethefuse,pryingit
fromunderneathusingyourthumbora
softinstrument.
5. Ifyouhaveaccesstoamultimeter,checkforcurrentflowacrossthetwonodesofthe
fuse.Ifyoudonot,simplyinspectthefilamentofthefuse.
6. Ifthefuseseemstobeblown,replaceitwithan
identicalfuse,asisidentifiedinthe
figuretotheright.
7. Restoreanyunpluggedconnections.
8. SecuretheITCboardandelectricalboxtothegrillusingthetwoPhillips‐headscrews.
A1‐1/4“x1/4”,5Amp,120
Volt,Fast‐BlowCartridge
Fuse
