Unpacking and Assembling Your Memphis Wood Fired Convection Grill.
Please note that during shipping some movement may have taken place, so a complete visual
inspection is required. Be sure to inspect entire grill after removing the protective shipping carton.
Report any damage to your local dealer immediately. Shipping damage is not covered under warranty.
Some surfaces may be sharp so wear gloves when assembling. Do not plug in the grill until it's fully
assembled, the plastic protective film is removed from all stainless steel surfaces, and you're ready to
cook. See: “start up procedure” for more details.
Your carton will contain the following:
1 - Grill head with ITC mounted in front
2 - Large cooking grates
1 - Integrated heat deflector / flavorizer
4 - Grill legs
1 - Base bottom
1 - Hardware bag with owner’s manual
1 - Shelf kit
Tools Required
Two 3/8” open end wrenches for leg and base assembly
Phillips Head screw driver
Rubber mallet to install caster sockets
Unpack and Identify Primary Components and Hardware (See “Wheel Kit”)
16 - ¼-20 X 2” Bolts
16 - ¼-20 Serrated flange nuts
4 - Caster sockets
4 - Push in casters
Shelf Kit Includes:
2 - Shelf tops
2 - Shelf bracket right
2 - Shelf bracket left
12 - #10 Self-tapping screws
Procedure for Assembly – See Diagrams on the following pages.
