Procedure to Convert This Fireplace to Burn LPG
This Fireplace arrives from the factory ready to burn natural gas. If you intend to burn LPG, it is recommended that you convert
this fireplace and its pressure regulator, pilot orifice slider position and burner orifices prior to placing this fireplace in its framed
cavity. See diagrams, on this page, and follow these instructions to prepare this fireplace for conversion to LPG.
1. Using a ¼” Hex Driver, remove 4 screws that secure the two burner tubes to the burner Airbox (adjacent to Pilot Light)
and the Burner Airbox (on firebox back wall).
2. Slide burner tubes to the right and lift out of firebox.
3. Carefully lift Burner Airbox, with Front Grate attached, out of firebox.
4. Turn off gas supply at the appliance service valve if gas line has been
connected to this appliance.
5. Remove the left-side Valve Access Cover plate by removing eight (8) ¼” hex
screws.
