Mendota FV48 - Page 88

85-03-01194 FV48 Page 88
Convection Air Blower System Parts
Figure 6-3 FV48 BLOWER ASSEMBLIES
Accent Light Parts
Note: LIGHT BULB TYPE G9 XENON, 25W is available at local hardware stores.
Figure 6-4 FV48 Accent Light System Parts
HA-110-00002
LEFT BLOWER ASSEMBLY
15-02-00130
EBM BLOWER LH, ROTATED
HA-110-00003
RIGHT BLOWER ASSEMBLY
15-02-00129
EBM BLOWER, RH ROTATED
65-02-01032
FV36 BLOWER GASKET
HA-77-00357
HA-88-00168
HA-58-04606
10-11-00020
10-11-00025
LIGHT COVER CLIP
LENS RETAINER BRACKET WITH GASKET
ACCENT LIGHT HOUSING
LIGHT BULB, G9 XENON, 25W
ACCENT LIGHT LENS-2016
