38 | P a g e
Figure 16
Figure 17
V min
H1 +H2 max
24 in.
2 ft.
30 in.
9 ft.
36 in.
15 ft.
42 in.
21-1/2 ft.
48 in.
28 ft.
4 ft. - 10 ft.
28 ft.
10 ft. - 40 ft.
Varies
V1 min
H1 +H2 max
V2 MAX
24 in.
2 ft.
10 ft.
30 in.
9 ft.
10 ft.
36 in.
15 ft.
10 ft.
42 in.
21-1/2 ft.
10 ft.
48 in.
28 ft.
10 ft.
4 ft. - 10 ft.
28 ft.
Varies
10 ft. - 40 ft.
Varies
Varies
