59 | P a g e
ML47 VALVE ASSEMBLY REPLACEMENT PARTS
ML47 VALVE ASSEMBLY REPLACEMENT PARTS LIST
ITEM
QTY
PART
NUMBER
DESCRIPTION
1
1
05-04-00062
Pilot Assembly
2
2
65-14-00180
ORIFICE, 1/8”
3
1
HA-90-00004
Proflame Valve Assembly with fittings
4
1
55-02-00070
TUBING, 3/8" OD X 12 SS 304
Figure 22: ML47 VALVE ASSEMBLY
