b. Loosen the 15 mm nut so it is almost completely off.
a - Clamp screw nut
b - Rubber boot
c. Loosen the 6 mm Allen socket head pivot screw.
63259
6 mm Allen socket head pivot screw
a
b
63258
FEATURES AND CONTROLS
34 eng
