OUTBOARD INSTALLATION
112 eng
Fastening the Outboard to the Transom
MOUNTING BOLTS
Outboard Transom Mounting Hardware ‑ Supplied with Outboard
Part Number Part Name Description
10‑67755‑1 Outboard mounting bolt
½‑20 x 4.50 in. long (2.25 in.
thread)
11‑826711‑17 Nylon insert locknut ½‑20
12‑28421 Flat washer 1‑1/2 in. diameter
12‑54012 Flat washer 7/8 in. diameter
Available Outboard Mounting Bolts
Part Number Description
10‑67755005 ½‑20 x 2.50 in. long (1.25 in. thread)
10‑67755006 ½‑20 x 3.50 in. long (1.25 in. thread)
10‑814259 ½‑20 x 4.00 in. long (2.25 in. thread)
10‑67755‑1 ½‑20 x 4.50 in. long (2.25 in. thread)
10‑8M0033366 ½‑20 x 5.00 in. long (3.25 in. thread)
10‑67755‑003 ½‑20 x 5.50 in. long (3.25 in. thread)
10‑67755‑2 ½‑20 x 6.50 in. long (2.75 in. thread)
10‑8M0028080 ½‑20 x 7.50 in. long (2.75 in. thread)
10‑8M0032860 ½‑20 x 8.00 in. long (2.75 in. thread)
