GENERAL INFORMATION
42 eng
Component Identification
a - Top cowl
b - Bottom cowl
c - Water pump indicator hole
d - Driveshaft housing
e - Anti‑ventilation plate
f - Auxiliary tilt switch
g - Transom brackets
h - Gearcase
i - Cooling water intake holes
