FEATURES AND CONTROLS
58 eng
3. Disengage the tilt support lever by raising the outboard off
the support lever and rotating the lever down. Lower the
outboard.
a - Tilt support lever
b - Knob
MANUAL TILTING
If the outboard cannot be tilted using the power trim/tilt switch,
the outboard can be manually tilted.
NOTE: The manual tilt release valve must be tightened before
operating the outboard to prevent the outboard from tilting up
during reverse operation.
Turn out the manual tilt release valve three turns
counterclockwise. This allows manual tilting of the outboard. Tilt
the outboard to the desired position and tighten the manual tilt
release valve.
SHALLOW WATER OPERATION
When operating your boat in shallow water, you can tilt the
outboard beyond the maximum trim range to prevent hitting
bottom.
1. Reduce engine speed below 2000 RPM.
2. Tilt outboard up. Make sure all the water intake holes stay
submerged at all times.
