OUTBOARD INSTALLATION
105
2. Attach the throttle cable to the throttle lever. Secure with a
washer and locknut. Tighten the locknut to the specified value.
a
b
or107
a - Nylon washer
b - Locknut
Description Nm lb. in. lb. ft.
Throttle cable locknut "b" Tighten then loosen 1/4 turn.
3. Adjust the cable barrel so that the installed throttle cable will
hold the idle stop screw against the stop.
a - Barrel sleeve
b - Cable barrel
c - Idle stop screw
4. Check the throttle cable adjustment as follows:
a. Shift the outboard into gear a few times to activate the
throttle linkage. Rotate the propeller shaft while shifting into
reverse.
b. Return the remote control to neutral.
