Mercury 200 User Manual

OUTBOARD INSTALLATION
89
Tube Ref No. Description Where Used Part No.
95
2-4-C Marine
Lubricant with Teflon
O-ring seal and entire
cable end
92-802859A1
2. Insert steering cable into tilt tube.
3725
3. Torque nut to specification.
3727
Description Nm lb. in. lb. ft.
Nut 47.5 35
Steering Link Rod Fasteners
IMPORTANT: The steering link rod that connects the steering
cables to the engine must be fastened using special washer head
bolt (P/N 10‑849838) and self‑locking nylon insert locknuts (P/N
11‑826709113). Never replace locknuts with common nuts
(non‑locking) as they will work loose/vibrate off freeing link rod to
disengage.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
