Mercury 200 User Manual

OUTBOARD INSTALLATION
107
2. Place the neoprene wrap around the wiring, hoses, and
control cables, and place into the lower half of the front clamp.
a
b
29073
a - Neoprene wrap
b - Lower half of the front clamp
3. Join the top half of the front clamp with the bottom half. Secure
both halves together with cables ties.
a
b
29074
a - Top half of the front clamp
b - Cable ties
4. Secure the front clamp into the bottom cowl with the retainer
and two screws.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
