Mercury 200 User Manual

GENERAL INFORMATION
33
Models 200 3.0 Liter 225 250
Cylinder Bore 92.1 mm (3.626 in.)
Stroke 76.2 mm (3.000 in.)
Recommended Spark
Plug
Champion QL77CC
1.
Spark Plug Gap 0.90 mm (0.035 in.)
Gear Ratio 1.75:1
Recommended
Gasoline
Refer to Fuel & Oil
Recommended Oil
Refer to Fuel & Oil
Gearcase Lubricant
Capacity
798 ml (27 fl. oz.)
Battery Rating
630 Marine Cranking Amps (MCA) or 490 Cold
Cranking Amps (CCA) or Amp Hours 80
Charging System
Output
60 Amps
1. Use only Champion QL77CC Spark Plugs or alternate spark plugs approved
by Mercury Marine in these models. Consult a Mercury Marine authorized
dealer before replacing spark plugs. Use of improper spark plugs may cause
engine damage.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
