Mercury 200 User Manual

MAINTENANCE
71
• Alternator Belt Tensioner Pivot Shaft ‑ Lubricate through
fitting.
29300
• Swivel Bracket ‑ Lubricate through fitting.
• Tilt Support Lever ‑ Lubricate through fitting.
a
b
27873
a - Swivel Bracket b - Tilt support lever
• Tilt tube ‑ Lubricate through fitting.
27874
!
WARNING
Incorrect cable lubrication can cause hydraulic lock, leading to
serious injury or death from loss of boat control. Completely
retract the end of the steering cable before applying lubricant.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
