Mercury 200 User Manual

MAINTENANCE
74
4. Remove vent plug and fill/drain plug and drain lubricant.
a
b
22692
a - Vent plug b - Fill/drain plug
GEARCASE LUBRICANT CAPACITY
Gearcase lubricant capacity is approximately
970 ml (32.8 fl. oz.).
GEARCASE LUBRICANT RECOMMENDATION
Mercury or Quicksilver High Performance Gear Lubricant.
CHECKING LUBRICANT LEVEL AND REFILLING
GEARCASE
1. Place outboard in a vertical operating position.
2. Remove vent plug/sealing washer.
3. Remove fill/drain plug. Place lubricant tube into the fill hole
and add lubricant until it appears at the vent hole.
a
b
22693
a - Vent hole b - Fill hole
IMPORTANT: Replace sealing washers if damaged.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
