Recording Serial Number
It is important to record this number for future reference. The serial number is
located on the outboard, as shown.
a - Model designation
b - Serial number
c - Certified Europe insignia (as applicable)
Specifications
Attribute
SeaPro 500hp V12
Horsepower 500
Kilowatts 373
Full throttle RPM range 5000–5800
Idle RPM in neutral gear* 700
Idle charge compensation** 700–825
Troll control RPM limit 700–1100
Number of cylinders 12
Displacement
7.6 L
7,556 cc (461 cid)
Cylinder bore 96 mm (3.8 in.)
Stroke 87 mm (3.4 in.)
Spark plug
NGK ILKAR7K11S
or
NGK ILKAR7G9
Spark plug gap 0.9 mm (0.035 in.)
Spark plug hex size 14 mm
a
71883
Model Number
Serial Number
HP KW
LB
KG
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA from
US and foreign components
XXXXXXXXX
XXXXXXXX
XXXX
b
c
GENERAL INFORMATION
14 eng
