Badge Dim This allows the brightness of the power button illumination to be varied. This
option does not affect the brightness of the front panel display.
To adjust the power button illumination brightness, use the Rotary Control to
outline the Badge Dim options box in the System menu - Figure 25, then briefly
press the Rotary Control. The number in the box will be highlighted. Turning the
Rotary Control counter clockwise will reduce the number in the box and also reduce
the power button illumination brightness. Turning the Rotary Control clockwise will
increase the number in the box and also increase the power button illumination
brightness. When the required illumination level has been set, briefly press the
Rotary Control to confirm the selection. The display will revert to the System menu,
Figure 25, with the new power button illumination setting shown in the Badge Dim
options box.
Screensaver: If 10 minutes elapse without any changes being made to the unit’s control settings,
the front panel display will go blank. This is to preserve the life of the display. To turn the display back
on, turn or briefly press the Rotary Control, or briefly press the front panel power button.
