Section 3
Prepare Parts for Assembly
Copyright 2002 Maintenance Manual MM-0230
Page 16 ArvinMeritor, Inc. Issued 07-02
Pinion Cone Variation Number
NOTE: Don’t use the pinion cone variation
number when you check for a matched gear set.
Use this number when you adjust the pinion depth
in the carrier. Refer to Section 4.
Pinion Cone
(PC) Variation
Number
Drive Pinion
Location
Ring Gear
Location
PC+3
+2
+0.01 mm
PC-5
–1
–0.02 mm
At the end of the
pinon gear head
On the outer
diameter
