Merrychef 402s Service & Parts Manual

18
402s Ovens Part. N
o.
32Z3539 Issue 5
Ref.
No.
Description Part No.
32 Fuse Holder 30A 30Z1178
34 Fuse Holder 10A 30Z0231
35 Grease Filter ( 2 parts ) SA339
SA340
36 Stirrer Glass DV0492
37 Rack Support DV0114
38 Upper Impinger plate SA211
39 Rack DV0275
40 Lower Impinger plate SA266
41 Top Trim DV0187
42 Rear Panel SA329
43 Side Panel LH DV0091
45 Door Skin DV0501
46 Door Handle 32Z1066
47 Door Inner SA331
48 Door Choke DV0168
49 Door Seal (wide) DV0305
50 Bottom Trim DV0037
51 Side Panel RH DV0092
52 Door Assembly SA111
53 MenuKey Dust Cover DV0052
54 Power switch (On/Off) 30Z1318
55 Membrane GM Version
Version 2.0
DV0055
56 Front Panel Version 2.0 DV0036
57 Display Assembly
& Header Version 2.0
30Z1299
58 MenuKey Socket
11K0005
59 Sounder
SA257
60 Cool-down pan
32Z4028
Part number identification chart 2
Ref.
No.
Description Part No.
61 Oven tray MC3175
62 Handle Assembly SA267
63 Griddle DV0221
64 Griddle carrier SA350
65 Chicken Griddle
(SA350+DV0221+ DV0267)
SA133
66 GM Membrane Version 3.0 DV0254
67 Front Panel Version 3.0 DV0249
68 Display Assembly
Header Version 3.0
30Z1324
70 Diode Assembly 11M0364
71 Solid State Relay 30Z1632
72 Fibre Optic Logic PCB 11K0013
73 Magnetron Cooling Duct LH DV0039
74 Magnetron Cooling Duct RH DV0040
— Door seal sealant ( tube ) 31Z0186
— Stirrer cover sealant ( tube ) 31Z0527
— Grease Filter Cartridge SA340
— Microswitch interlock Spring 31Z1247
