Merrychef 402s Service & Parts Manual

17
402s Ovens Part. N
o.
32Z3539 Issue 5
Ref. No. Description Part No.
1 Cavity High limit Stat 30Z1024
2 Motor Start Capacitor 2µF ( Blue ) 30Z1298
3 Filter 16A 30Z1340
4 Air filter SA276
5 Stirrer motor Assembly SA288
5A Stirrer (inside cavity) SA213
6 Microswitch SW1, SW2, SW3, SW4 30Z1294
7 Door Hinge Assembly RH SA202
8 Magnetron Cooling Fan 30Z1295
9 Door Hinge Assembly LH SA203
10 Motor Controller 30Z1319
11 Fuse 10A HRC 30Z0217
12 Gold resistor ( 220R ) 30Z0235
13 Relay PCB Assembly 11K0004
14 Ribbon Cable 15way 11Z0298
15 Ribbon Cable 10way MenuKey 11M0117
16 Logic PCB Version 2.0/ 2.5 11K0002
16 Logic PCB Assembly Version 3.0 11K0012
17 Transformer LT (Low voltage) 30Z1155
18 Fuse 1A 30Z0957
19 Cable Gland 31Z0500
Cable Gland Nut 31Z0499
20
Heater Element 220V 650W
DV0606
Heater Element 240V 650W
DV0607
21 Magnetron (Toshiba)
30Z1349
22 Magnetron Thermistor Assembly
SA234
23 Convection ( Hot Air ) Motor Assembly
SA208
24 Thermistor Cavity
30Z1315
25
HV Capacitor 2500V 1.0µF ( 50Hz Models)
30Z1331
25
HV Capacitor 2500V 0.88µF ( 60Hz Models )
30Z1251
25A HV Capacitor clip universal
31Z1261
26
HV Capacitor 2500V 1.1µF (50Hz Models)
30Z1242
26A HV Capacitor clip universal
31Z1261
27
Transformer 208/220/240V 50Hz
30Z1233
27
Transformer 208/220/240V 60Hz
30Z1230
28 HT Diode Assy
11H0010
29 Electrical Supply Lead Assembly
SA226
29A Electrical Supply Lead Assembly Twin Phase
SA225
30 Terminal Block
31Z0447
31 Fuse 20A FLM
30Z1177
Part number identification chart 1
